Dzus D8 Yamaha R1 2015-2019 D Ring Bolt Black
Dzus D8 Yamaha R1 2015-2019 D Ring Bolt Black 8 Pack
Dzus D8 Yamaha R1 2015-2019 D Ring Bolt Black
Dzus D8 Yamaha R1 2015-2019 D Ring Bolt Black 8 Pack

Yamaha 15-19 R1 Dzus Kit, DZUS (D8), D-Ring, Black Finish, WL=14mm

$32.00 USD
/
Shipping calculated at checkout.
DESCRIPTION FITMENT SHIPPING & RETURNS PART NUMBER(S) ADDITIONAL INFO
DESCRIPTION
Yamaha R1 '15+ Dzus Kit - D-Ring - Black Finsih - Icon 2015-2019 Yamaha R1 Dzus® Appearance Upgrade Kit
Complete 8pcs Kit for upgrading the Yamaha OEM Dzus® bolts to a Black Finish, with a D-Ring Head shape.

Kit Includes:
8 - 6mm D-Ring Panex D8 Fasteners Length: 14mm
Coating: Zinc Plate with BLACK Chromate
16 - Retaining Washers. Material: High density polyethylene
  • Mounting Information:
  • Mount first (1) washer between the bolt head and the paint for scratch protection.
  • Optional: Mount second (1) washer after inserting bolt though bodywork to hold Dzus® bolt to bodywork and prevent lose
Yamaha R1 2015+ Dzus Kit - Main Image - KitContents - Black D-Ring
Yamaha R1 2015+ Dzus Kit - Lower Side Image - D-Ring - Black Finish
Yamaha R1 2015+ Dzus Kit - Top Image - D-Ring - Black Finish

Dzus®  Bolts Specs & Drawing
Dzus Panex D8 Bolt Specs - Drawing
Additional Dzus®  Bolt Specs / Info

  • (L) Working Length: 14mm
  • Shaft Length : 17mm
  • Grip Range: 5.5mm to 7.4mm
    • Maximum Grip with out washers
    • Minimum Grip using 2 washers
  • Minimum bodywork Hole size: 6.2mm
    • English: 1/4 Inch

Dzus® is a Registered Trademark of Southco Inc.
