Titanium Drain Bolt - M14x1.50x18mm - Flush Mount (KGO-4)

Regular price
$19.00 USD
Sale price
$19.00 USD
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

Fits Yamaha R1 (15- ) & R6 (99- ) Motorcycles

Replaces P/N:

  • 90340-14019-00
  • 90340-14132-00.
DESCRIPTION FITMENT SHIPPING & RETURNS PART NUMBER(S) ADDITIONAL INFO
DESCRIPTION



KurveyGirl TitaniumFlush Mount Drain Bolt M14 - Left Side - Yamaha R1 Titanium Flush Mount Drain Bolt: M14 x 1.5 x 18mm
For 2015+ Yamaha R1.
Also Fits Yamaha R6
KurveyGirl.com Flush Mount Titanium Drain Bolt:
  • Size: M14 x 1.5mm
  • Thread Length (L): 18mm
  • Thread Pitch: 1.5mm
  • Material: Titanium






Yamaha R1 R6 KurveyGirl Flush Mount Titanium Drain Bolt M14

Kit Includes:
Features:

  • Titanium [Grade 5 - Ti6Al4V]
  • Flush Mount design that matches the Yamaha R1 flush mount
  • Pre Drilled for Safety Wire
  • T50 TORX Drive
  • 100% CNC Bolt from Billet Titanium with Rolled Threads
  • Thread: M14 x 1.5
  • Body Length (L): 18mm

Applications (Rule of Thumb):

Make Model Year OEM Drain Plug
Part Number
Yamaha YZF-R1 2015 - (Present)
90340-14019-00
YZF-R1M 2015 - (Present)
YZF-R1S 2016 - (Present)
FZ10 2017 - (Present)
Yamaha YZF-R6 1999 - (Present)
90340-14132-00
(Note: Replaces Hex-bolt type)

YZF-R6S 1999 - 2007
YZF-R1 1998 - 2014

Note: As all Rule's of Thumb, their are exceptions to the rule!!!
  • Please check your particular application.
  • Above information is for reference purposes only.





Part Images:
KurveyGirl Titanium Flush Mount Drain Bolt M14 - Right Iso - Yamaha R1 KurveyGirl Titanium Flush Mount Drain Bolt M14 - Right Side - Yamaha R1
KurveyGirl Titanium Flush Mount Drain Bolt M14 - Right Rear Iso - Yamaha R1 KurveyGirl Titanium Flush Mount Drain Bolt M14 - Left Rear Iso - Yamaha R1
KurveyGirl Titanium Flush Mount Drain Bolt M14 - Left Side - Yamaha R1 KurveyGirl Titanium Flush Mount Drain Bolt M14 - Left Iso - Yamaha R1



FITMENT

Fits Yamaha R1 (15- ) & R6 (99- ) Motorcycles

Replaces P/N:

  • 90340-14019-00
  • 90340-14132-00.


Applications (Rule of Thumb):

Make Model Year OEM Drain Plug
Part Number
Yamaha YZF-R1 2015 - (Present)
90340-14019-00
YZF-R1M 2015 - (Present)
YZF-R1S 2016 - (Present)
FZ10 2017 - (Present)
Yamaha YZF-R6 1999 - (Present)
90340-14132-00
(Note: Replaces Hex-bolt type)

YZF-R6S 1999 - 2007
YZF-R1 1998 - 2014

Note: As all Rule's of Thumb, their are exceptions to the rule!!!
  • Please check your particular application.
  • Above information is for reference purposes only.
