SPARE PARTS: One (1) Dzus-Pro Clip-On Fastener
DZUS Professional Grade Fastener: Replacement Clip-On Spring Retention system.
  • Note: No Bolt is included with these parts.
  • You Must have a compatible bolt, -45 Length Recommended, for this Clip-On Fastener to work together.
  • If you are not sure, we strongly recommend you purchase a replacement bolt at the same time.
Kit Includes:
1 - Dzus Pro Clip-On Fastener Coating: Zinc Trivalent Clear with Trivalent Chromate Clear.
Finish Specifications: ASTM-B-633, Type III, SC 2

Dzus Pro - Clip-On Fastner - Front View
Dzus Pro Clip-On Fastener: Front View

Dzus Pro - Clip-On Fastner - Rear View
Dzus Pro Clip-On Fastener: Rear View
Dzus Clip Specs & Drawing
Dzus Pro - Clip-On Plate Drawing
Dzus Pro Clip-On Specs / Info

  • Recommended hole center from edge: 10.7mm (.420in)
  • Minimum flat space for clip: 20mm
  • Minimum clearance behind bodywork:13mm
  • (H) Dimension:  7.1mm (.280in)
Dzus Clip Mounting Diagrams
Dzus Pro - Clip-On S-Spring - Install Diagram
Dzus Pro - Clip On
Mounting Dimensions
  • Suggested Inner Panel (Frame) Thickness:
    • 0.91mm ~ 3.25mm (0.036in - 0.128in)
  • Minimum Flat Panel Thickness: ~20mm (0.75 in)
  • Suggested Mounting Hole Diameter: 12mm (0.475 in)
  • Mounted S-Spring to the inside of the body
Dzus Pro - Clip-On S-Spring - Install Diagram 2
