Dzus Classic D3 Ducati 749 999 Dzus Kit Silver
Dzus D3 Ducati 749 Kit Silver

9pc: Ducati 749 & 999 Kit, Dzus Classic (D3), D-Ring & Button Head, Silver, WL=14mm

$60.00 USD Regular price
/
Shipping calculated at checkout.
  • In stock
  • Inventory on the way
DESCRIPTION FITMENT SHIPPING & RETURNS PART NUMBER(S) ADDITIONAL INFO
DESCRIPTION
Complete 9pc Kit for attaching a Dzus kit to newer Ducati 749 and 999 models.
  • This kit comes with both D-Ring Dzus bolts and Button head Dzus bolts.
  • All 9 dzus bolts plus clips for a Ducati 749 or 999 Models.
Note #1:  This kit fits most 749, 749D, 749S, 749R, 999 and 99S.  Some years of 999R models may require 7 Button Head Fasteners.  If you have questions, please contact me before buying.
Kit Includes:
4 - 6mm D-Ring Panex Fasteners Length: 14mm
Coating: Zinc Plate with Chromate
5 - 6mm Button Head Panex Fasteners Length: 14mm
Coating: Zinc Plate with Chromate
9 - 6mm Clip on Panex Retainers Coating: Zinc Plate with Chromate
20 - Retaining Washers. Material: High density polyethylene
2 extra washers for your tool box
Dzus Bolts Specs & Drawing
Additional Dzus Bolt Specs / Info

(L) Working Length: 14mm
Shaft Length : 17mm

Grip Range: 5.5mm to 7.4mm
Maximum Grip with out washers
Minimum Grip using 2 washers

Minimum bodywork Hole size: 7.2mm
English: 9/32nd Inch
Dzus Bolts Specs & Drawing
Additional Dzus Bolt Specs / Info

(L) Working Length: 14mm
Shaft Length : 17mm

Grip Range: 5.5mm to 7.4mm
Maximum Grip with out washers
Minimum Grip using 2 washers

Minimum bodywork Hole size: 7.2mm
English: 9/32nd Inch
Dzus Clip Specs & Drawing
Dzus Clip Specs / Info

Max hole from edge: 12mm

Minimum flat space for clip: 25mm

Minimum clearance behind bodywork:12mm
Grip Range: 5.5mm to 7.4mm
Maximum Grip with out washers
Minimum Grip using 2 washers
